Factory Professional Circuit Board Assemble A design clone turnkey service for 18 years PCBA
-
Highlight
A design clone PCBA
,18 years PCBA
,Turnkey service PCBA
-
TypeMultilayer Pcb
-
Number Of Layers4-layer
-
Base MaterialFR4
-
Copper Thickness1oz~4oz
-
Board Thickness0.15mm-6.5mm
-
Min. Hole Size0.20mm
-
Min. Line Width0.10(4mil)
-
Min. Line Spacing3 Mil
-
Surface FinishingHASL
-
Board SizeOSP
-
Testing ServiceAOI X-Ray Function Test
-
Line Width2 Mil
-
ServiceOne Stop Turnkey Service
-
PCB TestFixture Test
-
ItemDHL UPS EMS FEXDEX
-
Thicker Copper0.5-10 OZ
-
Layers1-28 Layers
-
CertificateRoHS
-
Solder Mask ColorBlue.green.red.black.white.etc
-
Via0.1mm
-
Place of OriginGuangdong China
-
Brand Namexzh
-
Model Numberpcba216
-
PriceCN¥720.98/pieces 1-99 pieces
Factory Professional Circuit Board Assemble A design clone turnkey service for 18 years PCBA
| Product Features | |
| Number of Layers | 4-layer |
| Testing Service | AOI X-Ray Function Test |
| Copper Thickness | 1oz~4oz |
| line width | 2 Mil |
| Min. Hole Size | 0.20mm |
| Service | One Stop Turnkey Service |
| PCB Test | Fixture Test |
| Model Number | pcba216 |
| Min. Line Spacing | 3 Mil |
| Solder mask color | Blue.green.red.black.white.etc |
| Min. Line Width | 0.10(4mil) |
| Via | 0.1mm |
| Brand Name | xz |
| Item | DHL UPS EMS FEXDEX |
| Type | Multilayer pcb |
| Board Size | OSP |
| Thicker Copper | 0.5-10 OZ |
| Layers | 1-28 layers |
| Base Material | FR4 |
| Board Thickness | 0.15mm-6.5mm |
| Surface Finishing | HASL |
| Certificate | RoHS |
Q: What is needed for PCB/PCBA quotation?
A: For Bare PCB project, please provide Quantity, Gerber file and specification like material, surface finish treatment, copper thickness, board thickness, soldermask color and silkscreen color and other special specs. For PCBA project, please provide above information as well, and BOM list, pick and place file. If you need turnkey service include programming and functional testing etc, kindly contact us for more details.
Q: Are my files safe?
A: Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third parties. We are willing to sign NDA effect by customer side local law and promising to keep customers data in high confidential level.
Q: What's your minimum of quantity(MOQ) ?
A: There is no MOQ.We are able to handle small as well as large volume production with flexibility.
Q: How to calculate the shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
Q: What other service do you have?
A: We mainly focus on PCB+Assembly+Components sourcing service. Additionally, we can also provide programming, testing, cables, enclosure assembly service.
Q: Can we inspect quality during production?
A: Yes, we are open and transparent on each production process. We Welcome you visit our factory to inspect our production process.
Our products are sold all over the world, you can rest assured.
