Shenzhen manufacture Rohs FR4 electronic pcba copper small circuit board printed bare pcb
-
Highlight
Electronic pcba
,Bare pcb pcba
,Shenzhen FR4 pcba
-
TypeSmart Electronics Pcba, Wireless Charging PCBA
-
Supplier TypeOEM/ODM
-
Copper Thickness1 Oz
-
Product NameXZH Bare Pcb
-
ServiceSurface Mount Technology
-
TechnicalImmersion Gold/Tin/Silver
-
Base MaterialFR4,Flexible.flex-rigid Board
-
Board Thickness20:1 (board Thickness: Hole Size)
-
Copper Weight1.0oz- 15.0oz
-
Inner Layer Copper Weight0.5oz- 12.0oz
-
NPTH Hole Size Toterance±0.025mm
-
CertificateCE FCC ROHS
-
Place of OriginGuangdong, China
-
Brand NameXZH
-
Model NumberXZH bare pcb
-
PriceCN¥111.76/pieces 1-99999 pieces
Shenzhen manufacture Rohs FR4 electronic pcba copper small circuit board printed bare pcb
Shenzhen manufacture Rohs FR4 electronic pcba copper small circuit board printed bare pcb
XZH: Your One-Stop ODM/OEM Solution Provider
PCB Prototype Features | Capability |
Quality Grade | Standard IPC 2-3 |
Number of Layers | 1 - 32 layers |
Order Quantity | 1 pcs + |
Material | Rigid: FR2, CEM-1, CEM-3, FR4 (standard - halogen free 一 high performance) including:ShengYi, Iteq, Elite Materials Corp., NanYa, Kingboard, Grace, TUC, Meteorwave |
Flex: PI, PET Including: Taiflex, Dupont FR & AP, Panason_x001f_ic, ShengYi, Doosan. Hanwha, SF305 | |
Lam, Laird TLAM SS laiflex, Dupont FR & AP, Panasonic, ShengYi, Doo Min Board Thickness - 1-2 (layers) 16mil 0.4mm san. Arion,Ventec and suggested local material brand( for detail pls contac | |
Board Size | Maximum610 x 1200mm( 24" x 47") |
Board Thickness | Rigid PCB : 0,15mm-10 mm |
FLEX PCB: 0.05mm-0.16mm | |
Copper Weight | 1.0oz- 15.0oz |
Min Trace/Space( track/gap or width/space) | 2mil/2mil (0.05mm/0.05mm) |
Solder Mask Color | Green, White, Blue, Black, Red, Yellow or others |
Silkscreen Color | White, Black or others |
Surface Finish | ENIG / GF / OSP /1 Ag / HASL (lead) / HASL (Leadfree) / Piating Au/Ni/ Immersion Sn / GF+OSP/ GF+HASL! OSP+ENIG /IAG+GF/lsn+GF |
Min Drilling Hole Diamete | mechanical :0.1mm Outline Tolerance ±4mil ±0.1 mm |
laser: 0.05mm S/M Pitch 3mil 0.08mm | |
NPTH Hole Size Toterance | ±0.025mm |
PTH Hole Size Tolerance | ±.003" (±0.08mm) - ±.006" (±0.15mm) |
Surface/Hole Plating Thickness | 20pm-30pm |
Aspect Ratio | 20:1 (board thickness: hole size) |
