Key Features:
|
|
1. Utilizes solar energy for charging during the day. The flashing module is turned off when the light is strong; at night or when the light is dim, it automatically starts flashing.
2. Supports simultaneous 3-way output, with each channel capable of delivering up to 1.5A of current. 3. Can be charged via solar panels, with a charging current of up to 3A. 4. Includes a reserved interface for a photoresistor sensor, allowing the choice between solar panels or photoresistor for light control. 5. Features a reserved interface for 12-hour or 24-hour mode selection, offering the option to light up only at night or around the clock. 6. Provides 8 lighting modes, including: 45 flashes/min (default), 30 flashes/min, 60 flashes/min, yellow and red slow flashing, three-channel (two-channel) strobe, single-channel fluorescent dot (breathing light), lane marker (three-channel), and crossing marker (three-channel). 7. 1. Supports a wide range of supply voltages (3.2V-24V), with typical supply voltages of 3.2V, 3.7V, 6V, 7.4V, 11.1V, 12V being compatible. 8. Features a low standby current of up to 180uA. 9. Includes a reserved programming interface, allowing for customized services. The solar-powered yellow and red slow-control board, solar-powered yellow and red fog light controller, with 8 selectable lighting modes, and an ultra-wide supply voltage range of 3.2V-20V. |
|
|
Sample Lead time
|
Mass production lead time
|
||
|
Single sided PCB
|
1~3 days
|
4~7 days
|
||
|
Double sided PCB
|
2~5 days
|
7~10 days
|
||
|
Multilayer PCB
|
7~8 days
|
10~15 days
|
||
|
PCB Assembly
|
8~15 days
|
2~4 weeks
|
||
|
Delivery time
|
3-7 days
|
3-7 days
|
||
|
Package: Anti-static Package with carton
|
|
|
||
