OEM FPC Fabrication Assembly Double Sided Flexible Printed Circuit Board Multilayer

OEM FPC Fabrication Assembly Double Sided Flexible Printed Circuit Board Multilayer

  • High Light

    OEM FPC Fabrication Assembly

    ,

    FPC Fabrication Assembly Double Sided

    ,

    Flexible Printed Circuit Board Multilayer

  • Type
    FPC, Flex Pcb
  • Base Material
    Polyimide, Copper And Ni/Au, Polyimide, Copper And Ni/Au
  • Copper Thickness
    1oz
  • Board Thickness
    1.6mm
  • Min. Hole Size
    0.2 Mm
  • Min. Line Width
    4mil
  • Min. Line Spacing
    4mil
  • Surface Finishing
    Immersion Gold, Immersion Gold
  • Board Size
    IPC-A-610 D/IPC-III Standard, IPC-A-610 D/IPC-III Standard
  • Solder Mask Color
    Yellow. Optional
  • Assembly Service
    FPCB
  • Name
    Double-Sided FPC Flexible Printed Circuit Board, FPCB Manufacturer
  • MOQ
    1pcs
  • Thickness
    0.2MM
  • Testing
    100% E-Testing
  • Place of Origin
    Guangdong, China
  • Brand Name
    XZH FPC
  • Model Number
    FPCB
  • Minimum Order Quantity
    100 pieces
  • Price
    $2.50/pieces 100-1999 pieces

OEM FPC Fabrication Assembly Double Sided Flexible Printed Circuit Board Multilayer



OEM Multilayer Pcb Gerber Pcb Manufacturing And PCBA Assembly One Stop Service
XZH: Your One-Stop ODM/OEM Solution Provider
OEM FPC Fabrication Assembly Double Sided Flexible Printed Circuit Board Multilayer 0

OEM FPC Fabrication Assembly Double Sided Flexible Printed Circuit Board Multilayer 1
Materials
PI, Copper and Ni/Au
Type
FPC
Layers
1-4 layers
Finished Board Dimensions
10*15mm, 250*380mm
Board Thickness
0.057 to 0.6mm
Finished Board Thickness Tolerance
±2 mils
Drill Hole Diameter
0.15 to 6.7mm
Finished Via Diameter
0.1mm (minimum)
Inner Layer Dielectric Thickness (1/2 mils PI with 15um adhesive)
0.0275 to 0.1mm
Hole Diameter Tolerance of PTH
±2 mils
Hole Diameter Tolerance of NPTH
±1 mil
Hole Position Tolerance
(compared with Gerber data)
±1 mil
Thickness of PTH Hole Copper
 8 to 30μm
Tolerance After Etching
± 30, 15% for impedance
Tolerance of Image to Image (minimum)
±3 mils
Tolerance of Image to Edge (minimum)
±2 mils
Cover Layer Registration (minimum)
6 mils
Punching Hole Diameter
0.1 to 5.0mm
Tolerance of Pasting Adhesive and Stiffener
±0.3mm
Punching Die Dimension Tolerance (hard die)
±4 mils
Punching Die Dimension Tolerance (soft die)
±12 mils
Impedance Tolerance (minimum)
±10%
SMT Tolerance and Pitch Width (minimum)
±4 mils
Want more information or would like to receive a quote? Click the CHAT NOW button at the top right to contact our salespeople.
