Smart Consumer Electronics PCBA Service Multilayer PCBA Board

Smart Consumer Electronics PCBA Service Multilayer PCBA Board

  • High Light

    Smart Consumer Electronics PCBA

    ,

    Consumer Electronics PCBA Service

    ,

    Multilayer PCBA Board

  • Type
    Smart Electronics Pcba
  • Supplier Type
    Customized
  • Copper Thickness
    1 Oz
  • Layers
    1-58 Layers
  • Certificate
    ISO TS16949
  • Surface Treatment
    HASL, HASL LF, Etc.
  • Solder Mask
    Double -sided Green LPI/ Customized
  • File Needed
    Gerber.etc
  • Application
    Electronic Devices
  • Material
    FR-4 / High TG FR-4 / Halogen Free.etc
  • Service
    Offer PCBA Design
  • Place of Origin
    Guangdong, China
  • Brand Name
    XZH
  • Model Number
    PCBA-120
  • Price
    $1.00/pieces >=1 pieces

Smart Consumer Electronics PCBA Service Multilayer PCBA Board



Professional Factory Toys PCB Circuit Board Multilayer pcb & pcba one stop service
XZH: Your One-Stop ODM/OEM Solution Provider
Smart Consumer Electronics PCBA Service Multilayer PCBA Board 0

Smart Consumer Electronics PCBA Service Multilayer PCBA Board 1
Specifications
Layers
1-58 layers
Board material
FR-4 / High TG FR-4 / Halogen Free material/Rogers/Arlon/Taconic/Teflon
Surface treatment
HASL, HASL lead free, Immersion Gold, Immersion Tin, r, Hard gold, Flash gold, OSP…
Silk screen colour
White / Black / Yellow
Solder mask colour
Green / Blue / Red / Black / Yellow / White
Smart Consumer Electronics PCBA Service Multilayer PCBA Board 2
Want more information or would like to receive a quote? Click the CHAT NOW button at the top right to contact our salespeople.
Smart Consumer Electronics PCBA Service Multilayer PCBA Board 3
Item
Capability
Base material
FR4,High-TG FR4,CEM3,aluminum, High Frequencey frequency(Rogers,Taconic,Aron,PTFE,F4B)
Layers
1-4 Layers(Alunimum), 1-32 layers(FR4)
Copper Thickness
0.5oz, 1oz, 2oz, 3oz,4oz
Dielectric Thickness
0.05mm, 0.075mm, 0.1mm,0.15mm,0.2mm
board Core Thickness
0.4mm,0.6mm, 0.8mm, 1.0mm, 1.2mm,
1.5mm, 2.0mm, 3.0mm and 3.2mm
Board Thickness
0.4mm - 4.0mm
Thickness Tolerance
+/-10%
Aluminum Machining
Drilling, Tapping, Milling, Routing, Die-Punching,
Break-off tab available
Min Hole
0.2 mm
Min Track Width
0.2mm (8mil)
Min Track Gap
0.2mm (8mil)
Min SMD Pad Pitch
0.2mm (8mil)
Surface Finishing
HASL lead free,ENIG,Plated Gold,Immersion Gold,OSP
Solder Mask Color
Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
Legend Color
Black, White etc
Assembly Types
Surface mount
Thro-hole
Mixed technology (SMT & Thru-hole)
Single or double sided placement
Conformal coating
Shield cover assembly for EMI emission control
Parts Procurement
Full Turnkey
Partial Turnkey
Kitted/Consigned
Component types
SMT 01005 or larger
BGA 0.4mm pitch, POP (Package on Package)
WLCSP 0.35mm pitch
Hard metric connectors
Cable & wire
SMT Parts Presentation
Bulk
Cut tape
Partial reel
Reel
Tube
Tray
Stencils
Laser-cut stainless steel
Other Techniques
Free DFM Review
Box Build Assembly
100% AOI test and X-ray test for BGA
IC programming
Components cost-down
Function test as custom
Protection technology
Customer Services
Smart Consumer Electronics PCBA Service Multilayer PCBA Board 4

PCB Service

XZH Supply single-side, double –side board, multilayer boards (1-20 layers), Boards type:Rigid PCB(CEM, FR4), Flexible PCB, Rigid-Flex PCB, MCPCB(Aluminum PCB), Ceramic PCB, RF PCB, etc.
Smart Consumer Electronics PCBA Service Multilayer PCBA Board 5

PCB Assembly&Components Sourcing

XZH offer Printed Circuit Board Assembly ,components Sourcing and complete solutions. what we can always gurantee is the best quality,competitive price and best service.
More Details or Other requirements welcome to Email and Chat with us.
Smart Consumer Electronics PCBA Service Multilayer PCBA Board 6
