Item
|
Capability
|
|
Base material
|
FR4,High-TG FR4,CEM3,aluminum, High Frequencey frequency(Rogers,Taconic,Aron,PTFE,F4B)
|
|
Layers
|
1-4 Layers(Alunimum), 1-32 layers(FR4)
|
|
Copper Thickness
|
0.5oz, 1oz, 2oz, 3oz,4oz
|
|
Dielectric Thickness
|
0.05mm, 0.075mm, 0.1mm,0.15mm,0.2mm
|
|
board Core Thickness
|
0.4mm,0.6mm, 0.8mm, 1.0mm, 1.2mm,
1.5mm, 2.0mm, 3.0mm and 3.2mm |
|
Board Thickness
|
0.4mm - 4.0mm
|
|
Thickness Tolerance
|
+/-10%
|
|
Aluminum Machining
|
Drilling, Tapping, Milling, Routing, Die-Punching,
Break-off tab available |
|
Min Hole
|
0.2 mm
|
|
Min Track Width
|
0.2mm (8mil)
|
|
Min Track Gap
|
0.2mm (8mil)
|
|
Min SMD Pad Pitch
|
0.2mm (8mil)
|
|
Surface Finishing
|
HASL lead free,ENIG,Plated Gold,Immersion Gold,OSP
|
|
Solder Mask Color
|
Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
|
|
Legend Color
|
Black, White etc
|
|
Assembly Types
|
Surface mount
Thro-hole Mixed technology (SMT & Thru-hole) Single or double sided placement Conformal coating Shield cover assembly for EMI emission control |
|
Parts Procurement
|
Full Turnkey
Partial Turnkey Kitted/Consigned |
|
Component types
|
SMT 01005 or larger
BGA 0.4mm pitch, POP (Package on Package) WLCSP 0.35mm pitch Hard metric connectors Cable & wire |
|
SMT Parts Presentation
|
Bulk
Cut tape Partial reel Reel Tube Tray |
|
Stencils
|
Laser-cut stainless steel
|
|
Other Techniques
|
Free DFM Review
Box Build Assembly 100% AOI test and X-ray test for BGA IC programming Components cost-down Function test as custom Protection technology |
|
|
Sample Lead time
|
Mass production lead time
|
||
|
Single sided PCB
|
1~3 days
|
4~7 days
|
||
|
Double sided PCB
|
2~5 days
|
7~10 days
|
||
|
Multilayer PCB
|
7~8 days
|
10~15 days
|
||
|
PCB Assembly
|
8~15 days
|
2~4 weeks
|
||
|
Delivery time
|
3-7 days
|
3-7 days
|
||
|
Package: Anti-static Package with carton
|
|
|
||
Our products are sold all over the world, you can rest assured.
