Smart Aluminum Board PCB 1oz - 20oz Copper Thickness PCBA Service

Smart Aluminum Board PCB 1oz - 20oz Copper Thickness PCBA Service

  • High Light

    Smart Aluminum Board PCB

    ,

    Aluminum Board PCB 1oz

    ,

    20oz PCBA Service

  • Base Material
    Aluminum Boards, FR-4 Glass Epoxy Laminate, Aluminium Base, RCC
  • Copper Thickness
    1-20oz
  • Board Thickness
    0.6-1.6MM
  • Min. Hole Size
    0.15MM
  • Min. Line Width
    0.15mm
  • Min. Line Spacing
    0.1MM
  • Surface Finishing
    Immersion Silver
  • Product Name
    Smart PCBA
  • Product Range
    PCBs In 1-28Layers,HDI,Aluminum Base
  • Max Board Size
    610*1200MM
  • Surface Finish Treatment
    Immersion Gold,Carbon Ink,Gold Fingers,Immersion Silver;Immersion Tin
  • Major Laminate
    King Board,ShengYi(S1141; S1170),Arlon,YGA-1-1;Rogers And Others
  • Via Holes
    18um 135um L 70um ~ 245um18um 1 35um L 70Oum ~ 210um
  • Min. Via Size And Type
    Dia. 0.15mm (Finished);Aspect Ratio = 12; HDI Holes (<0.10mm)
  • 100% Testing
    By ICT/FCT To Detect Potential Failures
  • PCB Design
    Schematic Capture,reverse Engineering
  • Port
    Shenzhen
  • Place of Origin
    China
  • Brand Name
    Original and New
  • Model Number
    XZH-PCBA
  • Price
    $0.50/pieces 1-9 pieces
  • Packaging Details
    1.Inner: Vacuum packing or Anti-static package;<br>2.Outer: Standard export carton;<br>3.Customized package.
  • Supply Ability
    300000 Piece/Pieces per Month

Smart Aluminum Board PCB 1oz - 20oz Copper Thickness PCBA Service

Shenzhen Xinzhanhong Experienced Aluminum Boards PCB Association For OEM PCBA Service

OFFICE AND FACTORY
Smart Aluminum Board PCB 1oz - 20oz Copper Thickness PCBA Service 0
Smart Aluminum Board PCB 1oz - 20oz Copper Thickness PCBA Service 1
Shenzhen xinzhanhong technology co,ltd
XZH PCBA based in Shenzhen but operating nationally, PCBA Technical Solutions specialise in commercial and retail HVAC and Mechanical projects. From our full design and quotation services, through to the installation, project management and maintenance teams, we are able to provide our clients with their full PCBA specification.

Rigid-Flex pcb( Fpcb) is a unique combination rigid PCB and flex PCB.
Advantage: It can be used to the PCB product which have special need for flexible region and rigid region, it is very helpful for saving the inner space of product, reducing volume of finish product and promoting properties of products.
Smart Aluminum Board PCB 1oz - 20oz Copper Thickness PCBA Service 2
Smart Aluminum Board PCB 1oz - 20oz Copper Thickness PCBA Service 3
XZH  have the capabilities, equipment, and experience to meet your needs and offer value-added services for all types of PCB layout, fabrication, and assembly.
Smart Aluminum Board PCB 1oz - 20oz Copper Thickness PCBA Service 4
Capabiity
Description
Technology & Capabilities




1. Product Range
Rigid PCBs from 2- 24 layers, HDI; Aluminium base




2. Min. Board Thickness
2 layer
4 layer
6 layer
8 layer
10 layer

min. 0.2 mm
0.4 mm
1 mm
1.2 mm
1.5 mm

12 & 14 layer
16 layer
18 layer
20 layer
22 & 24 layer

1.6 mm
1.7 mm
1.8 mm
2.2 mm
2.6 mm
3. Max. Board Size
610 x 1200 mm




4. Base Material
FR-4 Glass Epoxy laminate, Aluminium base, RCC




5. Surface Finish Treatment
Electroless nickel Immersion gold ( Electoless Ni/Au). Organic Solerability Preservatives ( OSP or Entek). Hot Air Leveling ( Lead- Free, RoHS). Carbon Ink. Peelable Mask. Gold Fingers. Immersion Silve. Immersion Tin. Flash gold ( Electrolytic)




6. Major Laminate
King Boad (KB-6150). ShengYi (S1141; S1170). Arion. YGA-1-1; Rogers and others.




7. Via Holes
Copper PTH/ Blind Via/ Buried Via/ HDI 2+N+2 with IVH




8. Copper Foil Thickness
18um/ 35um/ 70um~245um (outer layer 0.5oz~7oz)
18um/ 35um/ 70um~ 210um (inner layer 0.5oz~6oz)




9. Min. Via Size and Type
Dia. 0.15mm (Finished).
Aspect Ratiao = 12; HDI holes (<0.10mm)




10. Min. Line Width & Spacing
0.75 mm/ 0.10mm ( 3mil/ 4mil)




11. Min Via Hole Size & Pad
Via: Dia, 0.2mm/ pad. dia. 0.4mm; HDI<0.10mm via




12. Impedance I Control Tol.
+/- 10% ( min. +/- 7 Ohm)




13. Solder Mask
Liquid Photo- Image (LPI)




14.  Profiling
CNC Routing, V- Cutting, Punching, Push back punching, Connector chamfering




15.  Capacity
100 k㎡ output monthly




Smart Aluminum Board PCB 1oz - 20oz Copper Thickness PCBA Service 5
Smart Aluminum Board PCB 1oz - 20oz Copper Thickness PCBA Service 6
FAQ
1. What is needed for PCB & PCBA quotation in XZH PCBA?
XZHPCBA: For PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness, board
thickness).
For PCBA: PCB information, BOM,Testing documents.

2.What is needed for clone board quotation in XZH PCBA?
XZHPCBA: PCB size, clearly back and front picture of the board.

3.What is needed for PCB & PCBA design quotation?
XZHPCBA: Schematic or idea or function description of the board.(We can give a quotation with one of them, the more information
you have, the better.)

4.What is needed for components quotation?
XZHPCBA: Number and quantity of the components.

5.What is needed for assembly quotation?
XZHPCBA: BOM list, picture of finish product and assembly step.

6.What is needed for finish or semi-finished products PCB quotation?
XZHPCBA: Picture or specification.

7.What are the main products of your PCB/PCBA services in XZH PCBA?
XZHPCBA: Automotive, Medical, Industry Control, IOT, Smart Home, Military, Aerospace.

8. How to keep our product information and design file secret in XZH PCBA?
XZHPCBA: We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential
level.

9.what services can we provide in XZH PCBA?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
