Automotive PCB Assembly Services Double Sided PCBA Electronic Circuit Board

Automotive PCB Assembly Services Double Sided PCBA Electronic Circuit Board

  • High Light

    Automotive PCB Assembly Services

    ,

    Double Sided PCB Assembly Services

    ,

    PCBA Electronic Circuit Board

  • Type
    Motherboard Pcba
  • Supplier Type
    Customized
  • Copper Thickness
    1 Oz
  • Product Name
    OEM PCB PCBA Board Assembly
  • Layers
    1-58 Layers
  • Certificate
    ISO TS16949
  • Surface Treatment
    HASL, HASL LF, Etc.
  • Solder Mask
    Double -sided Green LPI/ Customized
  • File Needed
    Gerber.etc
  • Application
    Electronic Devices
  • Material
    FR-4 / High TG FR-4 / Halogen Free.etc
  • Service
    Offer PCBA Design
  • Place of Origin
    Guangdong, China
  • Brand Name
    XZH
  • Model Number
    PCBA-110
  • Price
    $1.00/pieces >=1 pieces

Automotive PCB Assembly Services Double Sided PCBA Electronic Circuit Board



Automotive Double Sided PCB PCBA Electronic Assembly Circuit Board Manufacture PCB Design Service
XZH: Your One-Stop ODM/OEM Solution Provider
Automotive PCB Assembly Services Double Sided PCBA Electronic Circuit Board 0

Automotive PCB Assembly Services Double Sided PCBA Electronic Circuit Board 1
Layers
1-58 layers
Board material
FR-4 / High TG FR-4 / Halogen Free material/Rogers/Arlon/Taconic/Teflon
Surface treatment
HASL, HASL lead free, Immersion Gold, Immersion Tin, r, Hard gold, Flash gold, OSP…
Silk screen colour
White / Black / Yellow
Solder mask colour
Green / Blue / Red / Black / Yellow / White
Capabiity
Description
Technology & Capabilities




1. Product Range
Rigid PCBs from 2- 24 layers, HDI; Aluminium base




2. Min. Board Thickness
2 layer
4 layer
6 layer
8 layer
10 layer

min. 0.2 mm
0.4 mm
1 mm
1.2 mm
1.5 mm

12 & 14 layer
16 layer
18 layer
20 layer
22 & 24 layer

1.6 mm
1.7 mm
1.8 mm
2.2 mm
2.6 mm
3. Max. Board Size
610 x 1200 mm




4. Base Material
FR-4 Glass Epoxy laminate, Aluminium base, RCC




5. Surface Finish Treatment
Electroless nickel Immersion gold ( Electoless Ni/Au). Organic Solerability Preservatives ( OSP or Entek). Hot Air Leveling ( Lead- Free, RoHS). Carbon Ink. Peelable Mask. Gold Fingers. Immersion Silve. Immersion Tin. Flash gold ( Electrolytic)




6. Major Laminate
King Boad (KB-6150). ShengYi (S1141; S1170). Arion. YGA-1-1; Rogers and others.




7. Via Holes
Copper PTH/ Blind Via/ Buried Via/ HDI 2+N+2 with IVH




8. Copper Foil Thickness
18um/ 35um/ 70um~245um (outer layer 0.5oz~7oz)
18um/ 35um/ 70um~ 210um (inner layer 0.5oz~6oz)




9. Min. Via Size and Type
Dia. 0.15mm (Finished).
Aspect Ratiao = 12; HDI holes (<0.10mm)




10. Min. Line Width & Spacing
0.75 mm/ 0.10mm ( 3mil/ 4mil)




11. Min Via Hole Size & Pad
Via: Dia, 0.2mm/ pad. dia. 0.4mm; HDI<0.10mm via




12. Impedance I Control Tol.
+/- 10% ( min. +/- 7 Ohm)




13. Solder Mask
Liquid Photo- Image (LPI)




14.  Profiling
CNC Routing, V- Cutting, Punching, Push back punching, Connector chamfering




15.  Capacity
100 k㎡ output monthly




Want more information or would like to receive a quote? Click the CHAT NOW button at the top right to contact our salespeople.
Automotive PCB Assembly Services Double Sided PCBA Electronic Circuit Board 2
Item
Capability
Base material
FR4,High-TG FR4,CEM3,aluminum, High Frequencey frequency(Rogers,Taconic,Aron,PTFE,F4B)
Layers
1-4 Layers(Alunimum), 1-32 layers(FR4)
Copper Thickness
0.5oz, 1oz, 2oz, 3oz,4oz
Dielectric Thickness
0.05mm, 0.075mm, 0.1mm,0.15mm,0.2mm
board Core Thickness
0.4mm,0.6mm, 0.8mm, 1.0mm, 1.2mm,
1.5mm, 2.0mm, 3.0mm and 3.2mm
Board Thickness
0.4mm - 4.0mm
Thickness Tolerance
+/-10%
Aluminum Machining
Drilling, Tapping, Milling, Routing, Die-Punching,
Break-off tab available
Min Hole
0.2 mm
Min Track Width
0.2mm (8mil)
Min Track Gap
0.2mm (8mil)
Min SMD Pad Pitch
0.2mm (8mil)
Surface Finishing
HASL lead free,ENIG,Plated Gold,Immersion Gold,OSP
Solder Mask Color
Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
Legend Color
Black, White etc
Assembly Types
Surface mount
Thro-hole
Mixed technology (SMT & Thru-hole)
Single or double sided placement
Conformal coating
Shield cover assembly for EMI emission control
Parts Procurement
Full Turnkey
Partial Turnkey
Kitted/Consigned
Component types
SMT 01005 or larger
BGA 0.4mm pitch, POP (Package on Package)
WLCSP 0.35mm pitch
Hard metric connectors
Cable & wire
SMT Parts Presentation
Bulk
Cut tape
Partial reel
Reel
Tube
Tray
Stencils
Laser-cut stainless steel
Other Techniques
Free DFM Review
Box Build Assembly
100% AOI test and X-ray test for BGA
IC programming
Components cost-down
Function test as custom
Protection technology
Customer Services
Automotive PCB Assembly Services Double Sided PCBA Electronic Circuit Board 3

PCB Service

XZH Supply single-side, double –side board, multilayer boards (1-20 layers), Boards type:Rigid PCB(CEM, FR4), Flexible PCB, Rigid-Flex PCB, MCPCB(Aluminum PCB), Ceramic PCB, RF PCB, etc.
Automotive PCB Assembly Services Double Sided PCBA Electronic Circuit Board 4

PCB Assembly&Components Sourcing

XZH offer Printed Circuit Board Assembly ,components Sourcing and complete solutions. what we can always gurantee is the best quality,competitive price and best service.
More Details or Other requirements welcome to Email and Chat with us.
